Star Micronics TSP700 Series - Connecting Usb Cable

– 7 –
ENGLISH
(5)Connect the interface cable to the connector on the rear panel of the printer.
(6)Fasten the connector clasps.
Parallel interface cable
3-1-3. Connecting USB Cable
Affix the ferrite core onto the USB cable as shown in the illustration below and
make sure to pass the cable through the cable support as shown in the illustration.
4 cm (maximum)
Ferrite core
