Star Micronics TSP700 Series - Appendix A: Specifications; General Specifications

– 88 –
APPENDIX
A-1. General Specifications
(1)Printing method Direct line thermal printing
(2)Print speed Max. 1440 dots/sec. (180 mm/sec.)
(3)Dot density 203 dpi: 8 dots/mm (0.125 mm/dot)
(4)Printing width Max. 80 mm
(5)Number of print columns
53 (12 × 24 dots)
(6)Roll paper Refer to chapter 2 for details on the recommended roll
paper.
Paper width: 79.5 ± 0.5 or 82.5 ± 0.5 or 57.5 ± 0.5 mm
Roll diameter: ø100 mm or less
(7)Overall dimension 147 (W) × 213 (D) × 148 (H) mm
(8)Weight Approx. 1.7 kg
(9)Noise Approx. 55 dB
Appendix A: Specifications
147 mm
148 mm
213 mm
