Elevation Calibration
Re-calibrating the 0% or 15% elevation may become necessary if the Elevation Motor
potentiometer goes out of range or looses range.
WHEN SHOULD ELEVATION CALIBRATION BE ENGAGED?
Elevation Calibration should be engaged in combination with the Motor Test Mode when
dealing with elevation issues and display codes such as EL RANGE and EL LOST
NOTE: Do not elevate treadmill above 15% = 57 (110v units), 80 (220v units) or below
0% = 240 (110 & 220v units) mechanical damage may occur.
1. Press and hold the “ 0 ”, “ 2 ” & “ START ” keys together. While holding the “ 0 ”
& “ START ” keys down, release the “ 2 ”. The display will beep and display
MAINTENANCE MODE.
2. Press and release the “8” key. Display will read: 240 3 .0 if the treadmill is at 0%
Note: If the treadmill is not at 0%, then press the elevation keys until the
unit is leveled at 0%.
3. Once the unit is leveled and the display is reading 240 3 .0 press the “0” key once, the
letter Z will be displayed for 0% setting. Press the key to save.
4. Pressing the INCLINE UP key until unit reaches desired maximum elevation (15%) “0”
Press the “ 0 “ key a second time the letter M will be displayed for 15% setting. Press
the key to save the above elevation.
NOTE: 110V units maximum elevation is 57 and 80 for 220v units.
5. Press key to exit Motor Test.
NOTE: Verify that the Elevation Motor Range (see above A column) is changing in
increments of 1% as the treadmill elevates up and down. Erratic increment changes would
indicate the display cable may be faulty.
