Starline S9 - Button Push Duration Definitions

Control commands
Definition of buttons push duration
Short push
Pushing one or two buttons once less than 1,5 sec.
Example: - first button short push; - short push of
first and second buttons simultaneously.
Long push
Pushing and holding a button or two buttons until melody and
vibration come up.
2 levels of a long pushing are envisaged:
 1 level long push – push and hold until a first melody.
Example: – 1 button long push;
 — 1 and 2 buttons long push simultaneously;
 2 level long push — push and hold until a second melody;
Example: — 4 button long push of a 2 level.
Double push
Double push of one button within 1 sec.
Example: — double push of 1 button.
Triple push
Triple push of one button button within 1 sec.
Example: — triple push of 1 button.
Sequential push
Double push of one or two buttons with different duration. First
pushing is long (1 or 2 level) and second push is short. Firs button
15
