MANUFACTURER menu
12
[IN2 WIND]
[IN2 STOP]
[IN2 SUSP]
[IN2 STAR]
[IN2 DIS]
=> This function has to be implemented
=> Auxiliary inlet 2 => Enabled to receive a signal from the outside to give a command STOP
irrigation (to be implemented).
=> Auxiliary inlet 2 => Enabled to receive a signal from the outside to give a command PAUSE
irrigation (to be implemented).
=> Auxiliary inlet 2 => Enabled to receive a signal from the outside to give a command START
irrigation.
=> Auxiliary outlet 2 => DISabled
Pressing _>_ takes you to a sub-menu with the following options:
[ENMA IN2]
[ENRU IN2]
[ENMU IN2]
=>ENables Modification by the Assistance
=>ENables Read-only by the User.
=>ENables Modification by the User
[IN3 WIND]
[IN3 STOP]
[IN3 SUSP]
[IN3 STAR]
[IN3 DIS]
=> This function has to be implemented
=> Auxiliary inlet 3 => Enabled to receive a signal from the outside to give a command STOP
irrigation (to be implemented). => Auxiliary outlet 3 => DISabled
=> Auxiliary inlet 3 => Enabled to receive a signal from the outside to give a command PAUSE
irrigation (to be implemented).
=> Auxiliary inlet 3 => Enabled to receive a signal from the outside to give a command START
irrigation.
=> Auxiliary outlet 3 => DISabled
Pressing _>_ takes you to a sub-menu with the following options:
[ENMA IN3]
[ENRU IN3]
[ENMU IN3]
=>ENables Modification by the Assistance
=>ENables Read-only by the User.
=>ENables Modification by the User
[420 DIS]
[420 ENAB]
=> Inlet 4-20 mA => DISabled
=> Inlet 4-20 mA => ENabled. (to be implemented).
Pressing _>_ takes you to a sub-menu with the following options suivants:
[ENMA 420]
[ENRU 420]
[ENMU 420]
=>ENables Modification by the Assistance
=>ENables Read-only by the User.
=>ENables Modification by the User
Pressing _>_ takes you to a sub-menu with the following options:
[MOT FLOW] Pressing _>_ takes you to a sub-menu with the following options relating to the MOTor which operates the FLOW
valve: ( WARNING: alter these parameters only if you are very familiar with the characteristics of reduction motors and
valves.)
[FOI 4.OA]
upper limit of current which the Flow valve motor can tolerate in the Opening phase ( I max = 5
Ampere).
[FCI 3.OA]
Upper limit of current which the Flow valve motor can tolerate in the Closing phase ( I max = 5
Ampere).
[TLF 150“]
Time Limit for activation which the Flow valve is allowed for reaching full opening or closing. If
the time limit is exceeded without the action being completed, the command to the motor is
cancelled and irrigation continues. The maximum programmable time is 250 seconds.
[MOT REG] Pressing _>_ takes you to a sub-menu with the following options relating to the MOTor which performs the REGulation
of the takeup speed. ( WARNING: alter these parameters only if you are very familiar with the characteristics of
reduction motors, valves and the irrigator.)
[RMI 4.OA]
Upper limit of current which the Regulating Motor can tolerate( I max = 5 Ampere).
[TLR 4O“]
Time Limit allowed for carrying out complete Regulation. If the time limit is exceeded without
the action being completed, the command to the motor is cancelled and irrigation continues. The
maximum programmable time is 250 seconds.
[SENSORS ]
By pressing _>_ a submenu appears with the following items:
SPeed SENSor applied to the irrigator: ROLLER or PINion with relative settings and tables.
PreSsure sensor and its enabling (always enabled).
Sensor of ReWinding End, its enabling (always enabled) and the opportunity to delay the cycle of irrigation end to let the
loading of the gun cart on the irrigator.
