Panel Controls and Terminals
UR-RT4 / UR-RT2 Operation Manual 7
7 [GAIN 1/2] knob
Adjusts the input signal level of the [MIC/LINE 1/2] jack.
8 [PHONES] knob
Adjusts the output signal level of the [PHONES] jack.
9 [PHONES ] jack
For connection to a set of stereo headphones.
) [OUTPUT] knob
Adjusts the output signal level of the [MAIN OUTPUT]
jacks.
