Using with a Computer
UR22C Operation Manual 23
Using with a Computer
Connection Example
NOTE
• When using the device with bus power supply, connect it to the USB 3.0 port of the computer.
• For the connector type of the computer to be connected to the device, refer to “Connector type of a computer” (page 33).
Microphone GuitarKeyboard Headphones
Front panel
Rear panel
When using the condenser
microphone, turn the switch
on after connecting it.
(Turn the switch off before
disconnecting it.)
Check!
Check!
Set all volume levels to
minimum before connecting
or disconnecting the
external device.
Computer Synthesizer/MIDI keyboard Monitor
speakers
When connecting an electric
guitar or electric bass, turn the
switch on after connecting the
instrument. (Turn the switch off
before disconnecting it.)
Check!
