Steinberg UR22C - Technical Specifications

Appendix
UR22C Operation Manual 37
Technical Specifications
MIC INPUT 1-2 (balanced)
Frequency Response +0.0/-0.3 dB, 20 Hz – 22 kHz
Dynamic Range 102 dB, A-Weighted
THD+N 0.003%, 1 kHz, -3 dBFS, 22 Hz/22 kHz BPF
Maximum Input Level +6 dBu
Input Impedance 4 kΩ
Gain Range +6 dB – +60 dB
HI-Z INPUT 2 (unbalanced)
Maximum Input Level +9.0 dBV
Input Impedance 1 MΩ
Gain Range 0 dB – +54 dB
LINE INPUT 1/2 (balanced)
Maximum Input Level +24 dBu
Input Impedance 18.5 kΩ
Gain Range -12 dB – +42 dB
MAIN OUTPUT (Impedance balanced)
Frequency Response +0.0/-0.2 dB, 20 Hz – 22 kHz
Dynamic Range 106 dB, A-Weighted
THD+N 0.0015%, 1 kHz, -1 dBFS, 22 Hz/22 kHz BPF
Maximum Output Level +12 dBu
Output Impedance 150 Ω
PHONES
Maximum Output Level 15 mW +15 mW, 40 Ω
USB
Specification USB 3.0, 32-bit, 44.1 kHz/48 kHz/88.2 kHz/96 kHz/176.4 kHz/192 kHz
XLR INPUT
Polarity 1: Ground
2: Hot (+)
3: Cold (-)
