Stellar 4500 Manual
9-1
Call 800-321-3741 to Order
ELECTRICAL COMPONENTS
P
ART#
D
ESCRIPTION
22600 TOGGLE SWITCH (HETRONIC RADIO REMOTE)
3
1661
T
OGGLE SWITCH (OMNEX RADIO REMOTE)
16975 E-STOP SWITCH (HETRONIC RADIO REMOTE)
35433 E-STOP SWITCH (OMNEX RADIO REMOTE)
3
5447
H
ANDLE / TRIGGER ASM (HETRONIC RADIO REMOTE)
3
1662
H
ANDLE / TRIGGER ASM (OMNEX RADIO REMOTE)
35916 CABLE BACK UP (HETRONIC RADIO REMOTE)
28832 CABLE BACK UP (OMNEX RADIO REMOTE)
3
1663
B
ATTERY COVER (OMNEX RADIO REMOTE)
3
5441
B
ATTERY TUBE (HETRONIC RADIO REMOTE)
D0045 ALARM (OVERLOAD)
34102 TRANSMITTER (HETRONIC RADIO SYSTEM)
3
4103
R
ECEIVER (HETRONIC RADIO SYSTEM
28837 TRANSMITTER (OMNEX RADIO SYSTEM)
28836 RECEIVER (OMNEX RADIO SYSTEM)
C4815 TOGGLE SWITCH (OPTIONAL FLOODLIGHTS AND SPEED CONTROL)
COMPRESSOR COMPONENTS (SHD66 OPTIONAL)
PART# DESCRIPTION
3853 PILOT VALVE 145/175 PSI
C4913 SOLENOID VALVE (SHD66 COMPRESSOR)
C4914 PRESSURE RELIEF VALVE (SHD66 COMPRESSOR)
C0864 AIR PRESSURE SWITCH -HOBBS (SHD66 COMPRESSOR)
7471 LOW PRESSURE INTAKE VALVE ASSEMBLY (SHD66 COMPRESSOR)
7472 HIGH PRESSURE INTAKE VALVE ASSEMBLY (SHD66 COMPRESSOR)
SERVICE KITS / FILTERS / LUBRICATION
P
ART#
DESCRIPTION
4559 AIR FILTER (SHD66 COMPRESSOR)
C6227 HYDRAULIC RETURN FILTER (CRANE / COMPRESSOR)
8825 SERVICE KIT - 200 HOUR (SHD66 COMPRESSOR)
8823 SERVICE KIT - 1-YEAR (CRANE / COMPRESSOR)
4460 MOLUBE GREASE-EXTERNAL GEAR TEETH FOR SWING GEAR BEARINGS)
C0087 SYNTHETIC COMPRESSOR OIL ( 1 QT )
MISCELLANEOUS COMPONENTS
PART# DESCRIPTION
12341 FLOOD LIGHTS (CRANE AND BODY)
5033 STROBE LIGHT (CRANE AND BODY)
HYDRAULIC SYSTEM COMPONENTS
P
ART#
D
ESCRIPTION
6397 OIL PRESSURE GAUGE
2
4960
F
LOW VALVE (PROPORTIONAL)
2
5369
S
EAL KIT (FLOW VALVE)
25367 RELIEF VALVE
2
5368
S
EAL KIT (RELIEF VALVE)
25371 SOLENOID VALVE (TANDEM)
2
5372
S
OLENOID VALVE (OPEN) - ROTATION FUNCTION
25373 SEAL KIT (TANDEM AND OPEN VALVES)
2
5370
C
OIL (FLOW VALVE AND SOLENOID VALVES)
4
9315
P
RESSURE SWITCH (OVERLOAD)
9803 COUNTER BALANCE VALVE (CYLINDERS)
D
1453
H
YDRAULIC SWING MOTOR
21151 GASKET (HYDRAULIC SWING MOTOR)
C
2027
O
RING (#4 FACE SEAL) (HYDRAULIC FITTINGS)
C
2028
O
RING (#6 FACE SEAL) (HYDRAULIC FITTINGS)
C2029 O RING (#8 FACE SEAL) (HYDRAULIC FITTINGS)
32223 O RING (#10 FACE SEAL) (HYDRAULIC FITTINGS)
D1245 O RING (#4 SAE PORT SIDE) (HYDRAULIC FITTINGS)
D1246 O RING (#6 SAE PORT SIDE) (HYDRAULIC FITTINGS)
D1247 O RING (#8 SAE PORT SIDE) (HYDRAULIC FITTINGS)
D1248 O RING (#10 SAE PORT SIDE) (HYDRAULIC FITTINGS)
1099 SEAL KIT (OUTRIGGER CYLINDER)
54579 SEAL KIT (MAIN AND SECONDARY CYLINDERS)
1100 SEAL KIT (EXTENSION CYLINDER)
ASSEMBLY COMPONENT PARTS
PART# DESCRIPTION
4381 BUSHING 2.00" X 2.00"
8819 BUSHING 2.00" X 1.00"
9320 PIN CAP 0.44" X 1.75" X0.25"
5145 PIN CAP 0.56" X3.00" X 0.25"
10172 CAP SCREW 0.50-13 X 1.00" GRADE 8
D0790 WASHER 0.50-13 SAE FLAT GRADE 8
C1592 GREASE ZERK 1/8 NPT STRAIGHT
9363 WEAR PAD 1.12" X 2.00" ROUND
6252 WEAR PAD 0.34" X 2.50" ROUND
3863 HOOK 5-TON
4485 BUSHING-HOOK
10710 SAFETY LATCH
27183 WORM GEAR (ROTATION GEAR BEARING)
27184 BEARING AND SEAL KIT (ROTATION GEAR BEARING)
3945 BUMPER DOCK
Chapter 9 - Replacement Parts
