Chapter 4 - Specificaitons
4-1
Chapter 4 - Specifications
Model 9628 Crane
SPECIFICATION SHEET
Crane Rating: 55,000 ft-lbs (7.6 ton-meters)
Standard Boom Length:
12’ 4” (3.28 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 96" (244 cm)
2nd stage: Hydraulic 96" (244 cm)
Maximum Horizontal Reach: 28’ 4” (8.64 m) from CL of Crane
Maximum Vertical Lift: 29’ 4” (8.94 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height: 34 inches (86.4 cm)
(crane only)
Mounting Space Required: 20” x 21” (50.8 x 53.3 cm)
Approximate Shipping Weight: 2850 lbs (1295 kg)
Controls: Radio control standard for all functions.
Winch Specifications
Rope Diameter: 3/8" (.953 cm)
Line pull speed: 60 ft/min (18.29 m/min)
Max. single part line: 4300 lbs (1950 kg)
Max. double part line: 8600 lbs (3900 kg)
Rotation: 400 degree power
(worm gear)
Lifting Capacities: 4450 lbs @ 12’ 4” (2020 kg @ 3.28 m)
1925 lbs @ 28’ 4” (875 kg @ 8.64 m)
Power Supply Required: PTO & Pump
(8 gpm @ 3000 psi)
(30.3 lpm @ 207 bars)
*Subject to change without notification
