Chapter 6 - Installation
General Installation
This chapter is designed to serve as a general
guide for the installation of a Stellar 9628
Telescopic Crane on a Stellar Service Body.
Each installation is considered unique so certain
portions of this chapter may or may not apply to
your direct application. If a question should arise
during the installation process, please contact
Stellar Customer Service at (800) 321 3741.
This crane is designed for use with a Stellar
Service Body installed on a vehicle that meets
the minimum chassis requirements of the crane.
Check with Stellar Industries before installing this
crane on a body other than a Stellar Service
Body.
Chapter 6 - Installation
6-1
WARNING!
The use of this crane on a body not
capable of handling the loads
imposed on it may result in serious
injury or death.
Installation Notice
According to Federal Law (49 cfr part 571), each
final-stage manufacturer shall complete the
vehicle in such a manner that it conforms to the
standards in effect on the date of manufacture of
the incomplete vehicle, the date of final
completion, or a date between those two dates.
This requirement shall, however, be superseded
by any conflicting provisions of a standard that
applies by its terms to vehicles manufactured in
two or more stages.
Therefore, the installer of Stellar cranes and
bodies is considered one of the manufacturers of
the vehicle. As such a manufacturer, the installer
is responsible for compliance with all applicable
federal and state regulations. They are required
to certify that the vehicle is in compliance with the
Federal Motor Vehicle Safety Standards and
other regulations issued under the National
Traffic and Motor Vehicle Safety Act.
Please reference the Code of Federal
Regulations, title 49 - Transportation, Volume 5
(400-999), for further information, or visit
http://www.gpoaccess.gov/nara/index.html for
the full text of Code of Federal Regulations.
Notice:
PTO and Pump installation instructions are
provided by the proper manufacturers. For
more information on which PTO and Pump fit
your application, please contact your local
Stellar Distributor or Stellar Customer Service.
Applicable Chassis:
Cab to Axle:
Body Length Nominal:
Body Height:
Body Width:
Compartment Depth:
Floor Width:
Net Weight:
19000 GVWR
and up.
84” (213.36 cm)
133” (337.82 cm)
52” (132.08 cm)
94” (238.76 cm)
22” (55.88 cm)
50” (127 cm)
3600 lbs (1632.93 kg)
Optimal Service Body for
the 9628 Crane:
T2-11 Service Body
Notice: Read this Page Before Installation of the Crane
The following pages will give a basic overview
of the installation process for the Stellar 9628.
Please read thru them entirely and obtain a
clear understanding of the process before
proceeding.
