28
650/800/850 GUEPARD
ELECTROMECHANICAL POWER STEERING
Electromechanical power steering (EPS)
Electromechanical power steering (EPS)
is designed to reduce the steering force
required to turn the directive wheels at low
driving speed, parking, and is installed in
the vehicle category T3b steering column.
To prevent its accidental
damage do not disassemble the EPS unit.
EPS system functions as follows:
The internal torque sensor automatically measures the
force and direction applied by the driver while steering,
end relays the information to the ECU. The vehicle speed
is also sent to the ECU and combined with the force and
direction signal. A calculation is made end this is sent
to the electric motor to create a controlled response
movement. This is all done through intelligent intelligent.
manufacture website : stelsoffroad.com
BRAKE LEVERS AND PEDAL 650/800/850 GUEPARD
29
Brake pedal
The vehicle category T3b brake pedal is
positioned on the right.
Brake pedal - front and rear wheels simultaneous
braking.
Hand-brake levers
Positioned on the steering wheel, on the left and
on the right. To slow down press the lever to the
steering wheel handle.
Left brake lever (1) - rear wheels braking.
Right brake lever (2) - front wheels braking.
manufacture website : stelsoffroad.com
