2 Mechanical structure
12 SA-112-0106V1.0-WEM-GB © F. Stephan GmbH
Fig. 5: Service flap
1 Intake filter 3 Oxygen sensor
2 Service flap
On the left and right side wall there are recessed handles for carrying the
A
LIA ventilator.
Some of the electronic controls and the power supply are accommodated
inside the ventilator.
Fig. 6: Electronic components
1 Power supply 3 Electronic controls
2 Cold device connector combination
2
1
3
1
2
3
