StepperOnline DM860T User Manual

Tel: 0086-2587156578 Web: www.omc-stepperonline.com
Email:sales@stepperonline.com
7
Full Digital Stepper Drive DM860T
Microstep Steps/rev.(for 1.8°motor) SW5 SW6 SW7 SW8
2 400
4 800
8 1600
16 3200
32 6400
64 12800
128 25600
256 51200
5 1000
10
2000
20 4000
25 5000
40 8000
50 10000
100 20000
200 40000
ON ON ON ON
OFF ON ON ON
ON OFF ON ON
OFF OFF ON ON
ON ON OFF ON
OFF ON OFF ON
ON OFF OFF ON
OFF OFF OFF ON
ON ON ON OFF
OFF ON
ON
OFF
ON OFF ON OFF
OFF OFF ON OFF
ON ON OFF OFF
OFF ON OFF OFF
ON OFF OFF OFF
OFF OFF OFF OFF
Current Settings
For a given motor, higher drive current will make the motor to output more torque, but at the same time causes more
heating in the motor and drive. Therefore, output current is generally set to be such that the motor will not overheat for
long time operation. Since parallel and serial connections of motor coils will significantly change resulting inductance
and resistance, it is therefore important to set drive output current depending on motor phase current, motor leads and
connection methods. Phase current rating supplied by motor manufacturer is important in selecting drive current,
however the selection also depends on leads and connections.
The first three bits (SW1, 2, 3) of the DIP switch are used to set the dynamic current. Select a setting closest to your
motor’s required current.
Dynamic Current Setting
Peak Current RMS Current SW1 SW2 SW3
2.40A 2.00A
3.08A 2.57A
3.77A 3.14A
4.45A 3.71A
5.14A 4.28A
5.83A 4.86A
6.52A 5.43A
7.20A 6.00A
ON ON ON
OFF ON ON
ON OFF ON
OFF OFF ON
ON ON OFF
OFF ON OFF
ON OFF OFF
OFF OFF OFF
Notes: Due to motor inductance, the actual current in the coil may be smaller than the dynamic current setting,
particularly under high speed condition.
