SteppIR 2 Element Yagi - ELEMENT TRUSS OVERVIEW

41
13406 SE 32nd St, BELLEVUE WA, 98005 WWW.CONSUMER.STEPPIR.COM TEL: (425)-453-1910
SKIP TO PAGE 46 IF YOU DO NOT HAVE THE 40/30 LOOP
ELEMENT TRUSS OVERVIEW
A
D
B
C
39 ft & 49 ft Loop Element Truss Kit
(not to scale)
Figure 7.30
Key Description A Element Truss coupler B Stainless steel turnbuckle C Element Truss Support D Dacron Rope E 1/8” Thimble
(3/16” for 49ft element)
F 1/8” Wire Clip
(3/16” for 49ft element)
F
E
Polyolefin heat shrink
Truss coupler butts up against heat shrink
SECTION 1
SECTION 2
SECTION 3
SECTION 4
BASE
TIP
