LED202 In-Ceiling Lighting System Operator Manual
Components
Light
See Figure 6-1 and refer to Table 6-1 for the light components.
Figure 6-1. Light Components
Table 6-1. Light Components
1 *
ON/OFF Switch
2 *
Gimbal Mechanism
3 *
Light Engine
4
Access Panel Lid/Cover
5
Front Window
* — Shown for reference only. Internal components should not be accessed by the Customer,
refer to qualified service personnel.
