6 — Components
14
Operator Manual LED202 In-Ceiling Lighting System
11042437_A
Wall Control Interface
See Figure 6-2 for the wall control interface components.
NOTE: A dual light system is shown for reference. Single light systems will only have controls for
“Light 1”.
Figure 6-2. Wall Control Interface Components
#
Component
1
Light 1 Position Controls
2
Light 1 Intensity Controls
3
Light 2 Position Controls
4
Light 2 Intensity Controls
To Next Page
