stertil COMBILOK - Page 56

52
DESCRIPTION
Foot protector
Switching device
Plate
-HMPE
Plate
-HMPE assembly
Plate
-HMPE
Wear plate
Sliding beam
Cross guide
Cover
Switch bracket
Cylinder "B" (See
fig. C)
Wear plate
Foot protector
Screw M5 x 20
Nut M10 H = 3 x D
Hex. bolt M10 x 30 DIN 933
-8.8
Washer M10 DIN 125A
Hex. bolt M16 x 50 DIN 933
-8.8
Washer M16 DIN 125A St
Hex. bolt M6 x 12 DIN 933
-8.8
Washer M6 DIN 125A St
Collar Ø15 DIN 705A St.
Special
nut M6
Washer M8 DIN 125A St
Hex. bolt M8 x 12 DIN 933
-8.8
Hex. bolt M8 x 20 DIN 933
-8.8
Hex. socket countersunc screw M8 x 20 DIN 7991
-8.8
Limit switch
Slotted screw M4 x 25 DIN 84
Sensor
Bolt M5 x 30 DIN 84
Screw M8 x 10 DIN 7991
Turnbuckle
Washer M5 DI
N 125-A
Special nut M5
Bracket
REFERENCE
Left model
03
-719-101
03
-719-110
03
-719-120
03
-719-615
Right model
03
-704-022
03
-704-023
03
-704-215
03
-704-044
03
-704-216
03
-704-046
03
-714-200
03
-714-100
03
-714-125
03
-714-150
0
3-700-550
02
-400-002
03
-704-024
1036.23.03.53
65
-052-900
65
-003-407
65
-055-210
1035.38.07.79
65
-055-216
1035.38.04.13
65
-055-204
1039.80.00.15
65
-052-914
65
-055-208
65
-003-359
65
-003-363
65
-025-066
1002.17.53.04
65
-030-226
69
-205-005
65
-030-257
65
-025-053
1002.15.00.56
65
-005-014
1002.11.00.32
03
-710-631
INDEX
1
2
3
4
5
6
7
8
9
10
11
12
13
14
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
FIG. B SAMENSTELLING DWARSSTUK
FIG. B AUFBAU DES QUERSTÜCKS
FIG. B ASSEMBLAGE DU PIECE TRANSVERSAL
FIG. B
ASSEMBLY CROSS-HEAD
