FIG. J HYDRAULISCHE UNIT
FIG. J HYDRAULIKAGGREGAT
FIG. J UNITE HYDRAULIQUE
FIG. J HYDRAULIC UNIT
INDEX REFERENCE DESCRIPTION
03-705-520 Hydr. unit assembly
*
03-710-525 Hydr. unit
1 68-900-021 Pressure switch 210 Bar
2 68-900-020 Pressure switch 50 Bar
3 68-703-001 Coupling EVW 6-PL
4 68-700-410 Coupling GE 6-PL/R 1/4"
5 68-700-418 Coupling GE 10-PL/R
6 68-703-003 Coupling EVW 10-PL
7 68-703-103 Coupling EVT 10-PL
8 68-705-103 Valve KH-10-PL
9 68-703-403 Coupling EVGE 10-PLR-ED
10 68-510-911 O-ring 110.72 x 3.53
*
11 325-06-103 Suction filter D.62 da 3/8"
*
12 03-700-527 Pump 3.8 cc
*
13 68-348-101 4/3-valve
*
14 69-481-504 Coil
*
15 68-512-140 O-ring 14 x 1.78 80 SH
*
16 68-510-124 O-ring 12.42 x 1.78
*
17 68-208-503 Pressure relief valve 230 Bar
*
18 325-06-108 Coupling pumpside "LP x MC"
*
19 325-06-109 Coupling motorside "LM x MC"
*
20 325-06-110 Electromotor MT 80 2.2 Kw
*
21 68-212-501 Return valve
*
22 03-705-521 Pipe 10 mm
23 68-703-203 Coupling EVL 10-PL
24 03-710-526 Breather cap ¾”
*
25 03-705-527 Tank 12 Ltr.
*
26 - Valve block/Pump casing
*
27 - Block
*
28 65-455-020 Copper ring
29 - Pressure relief valve 50 Bar
*
