ENGLISH
99
WARNING Electrocution
All 4locking tabs on the programming unit must click into
place. The locking tabs must be complete and undam-
aged. If the programming unit is not inserted correctly,
user protection against contact with live components
cannot be ensured.
Insert the connecting cable plug of the programming unit
into the PCB (see chapter "Commissioning/ Initial start-up").
Hook the appliance cover in at the bottom. Pivot the appli-
ance cover up to the back panel.
Secure the appliance cover.
Fit the cover onto the appliance cover.
14.13 Operation with preheated water
You can restrict the maximum inlet temperature by installing a
central thermostatic valve.
14.14 Pairing the mini wireless remote control
The mini wireless remote control can be paired via the program-
ming unit; see chapter "Settings/ Service/ Wireless/ Connect
other wireless subscribers".
However, if the programming unit is used outside the appliance (in
accessories), open the appliance and proceed as described below
to pair the mini wireless remote control.
D0000056234
12
1 Wireless module button for pairing and unpairing
2 Yellow LED illuminates when mini wireless remote control is
active
To start pairing the mini wireless remote control, briefly
press the button. The yellow LED starts to flash.
Now press the plus (+) button on the mini wireless remote
control for 3seconds. The red LED on the mini wireless
remote control indicates that a pairing telegram is being
sent.
Once pairing is completed successfully, the yellow LED goes out. If
pairing was unsuccessful, the LED continues to flash until pairing
mode ends (30seconds in total).
