INSTALLATION
SPECIFICATION
WPL 13 E WPL 13
cool
WPL 18 E WPL 18
cool
WPL 23 E WPL 23
cool
Electrical details
Frequency Hz 50 50 50 50 50 50
Current (with/without softstarter) A 24/- 24/- 26/- 26/- 30/- 30/-
Fuse - compressor A 3 x C 16 3 x C 16 3 x C 16 3 x C 16 3 x C 16 3 x C 16
Emergency/booster heater fuse A 3 x B 16 3 x B 16 3 x B 16 3 x B 16 3 x B 16 3 x B 16
Control circuit fuse A 1 x B 16 1 x B 16 1 x B 16 1 x B 16 1 x B 16 1 x B 16
Compressor phases 3/N/PE 3/N/PE 3/N/PE 3/N/PE 3/N/PE 3/N/PE
Phases, emergency/booster heater 3/N/PE 3/N/PE 3/N/PE 3/N/PE 3/N/PE 3/N/PE
Control phases 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE 1/N/PE
Rated voltage, emergency/booster heater V 400 400 400 400 400 400
Rated compressor voltage V 400 400 400 400 400 400
Rated control voltage V 230 230 230 230 230 230
Versions
Flow/return connection G 1 1/4 A G 1 1/4 A G 1 1/4 A G 1 1/4 A G 1 1/4 A G 1 1/4 A
Condenser material 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu
Refrigerant R407 C R407 C R407 C R407 C R407 C R407 C
Refrigerant capacity kg 3.2 5.9 3.4 5.2 3.4 4.9
Frost protection X X X X X X
Defrost method Circuit re-
versal
Circuit re-
versal
Circuit re-
versal
Circuit re-
versal
Circuit re-
versal
Circuit re-
versal
IP-Rating IP14B IP14B IP14B IP14B IP14B IP14B
Dimensions
Height mm 1116 1116 1116 1116 1116 1116
Width mm 784 784 784 784 784 784
Depth mm 1182 1182 1182 1182 1182 1180
Height (external installation) mm 1434 1434 1434 1434 1434 1434
Width (external installation) mm 1240 1240 1240 1240 1240 1240
Depth (external installation) mm 1280 1280 1280 1280 1280 1280
Height (internal installation) mm 1182 1182 1182 1182 1182 1182
Width (internal installation) mm 800 800 800 800 800 1240
Depth (internal installation) mm 1240 1240 1240 1240 1240 1390
Weights
Weight kg 210 210 220 220 225 225
Total weight - external installation kg 360 336 370 346 375 351
Total weight - internal installation kg 295 297 305 307 310 312
Connections
Air hose inlet and outlet connectors DN 560 DN 560 DN 560 DN 560 DN 560 DN 560
Values
Flow rate - cooling on the heat source side m³/h 3500 3500 3500
Heating flow rate (EN 14511) at A7/W35, B0/W35 and 5 K m³/h 1.45 1.55 2.22 2.12 2.85 2.64
Rated heating flow rate m³/h 1 1 1.39 1.39 1.94 1.82
Heating flow rate (min.) m³/h 1 1 1.2 1.2 1.4 1.4
Min flow rate - cooling m³/h 1.2 1.7 2.2
Flow rate, heat source side m³/h 3500 3500 3500 3500 3500 3500
Internal pressure differential - cooling hPa 70 80 130
Total available external pressure differential hPa 1.0 1.0 1.0 1.0 1.0 1.0
Max. available external pressure differential, inlet side hPa 0.8 0.8 0.8 0.8 0.8 0.8
Internal pressure differential hPa 70 70 110 110 200 200
