1.3 Other symbols in this documentation
Note
Notes are bordered by horizontal lines above and below
the text. General information is identified by the symbol
shown on the left.
Read these texts carefully.
Symbol
Damage to the appliance and environment
Appliance disposal
This symbol indicates that you have to do something. The ac-
tions you need to take are described step by step.
1.4 Information on the appliance
Appliance disposal
Appliances with this designation are unsuitable for gen-
eral waste disposal and should therefore be disposed of
separately.
1.5 Units of measurement
Note
All measurements are given in mm unless stated oth-
erwise.
1.6 Standardised output data
Explanations to determine and interpret the specified standardised
output data.
1.6.1 Standard: EN 14511
The output data specifically mentioned in text, diagrams and
technical datasheets has been calculated according to the test
conditions of the standard shown in the heading of this section.
Generally, these standardised test conditions will not fully meet
the conditions found at the installation site of the system user.
Depending on the chosen test method and the extent to which
this method deviates from the conditions defined in the norm
shown in the heading of this section, any deviations can have a
considerable impact.
Further factors that have an influence on the test values are the
measuring equipment, the system configuration, the age of the
system and the flow rates.
A confirmation of the specified output data can only be obtained
if the test conducted for this purpose is also performed in ac-
cordance with the conditions defined in the norm shown in the
heading of this section.
2. Safety
2.1 Intended use
The WPLE appliance is designed for central heating within the
application limits given in the specification.
The WPLcool appliance is designed for central heating and cooling
within the application limits given in the specification.
This appliance is designed for domestic use. It can be safely oper-
ated by untrained personnel. The appliance can also be used in a
non-domestic environment, e.g. in a small business, as long as it
is used in the same way.
Any other use beyond that described shall be deemed inappropri-
ate. Observation of this document is also part of the correct use
of the unit. Any changes or conversions to the appliance void any
warranty.
2.2 Safety instructions
Observe the following safety instructions and regulations.
- Only qualified contractors should carry out the electrical
work and installation of the heating circuit.
- Contractors are responsible for adherence to all currently ap-
plicable regulations during installation and commissioning.
- Operate the appliance only when fully installed and with all
safety equipment fitted.
!
WARNING Injury
The appliance may be used by children aged 8 and up
and persons with reduced physical, sensory or mental
capabilities or a lack of experience provided that they
are supervised or they have been instructed on how to
use the appliance safely and have understood the result-
ing risks. Children must never play with the appliance.
Children must never clean the appliance or perform user
maintenance unless they are supervised.
2.3 CE designation
The CE designation shows that the appliance meets all essential
requirements according to the:
- Electromagnetic Compatibility Directive
- Low Voltage Directive
- Pressure Equipment Directive
2.4 Test symbols
See type plate on the appliance.
3. Appliance description
The appliance is an air source heat pump that oper-
ates as a heating heat pump. The appliance extracts heat
from the outdoor air at a low temperature level and trans-
fers it to the heating water at a higher temperature level.
The heating water can be heated up to a flow temperature of 60 °C.
With the appropriate accessories, this appliance may be installed
internally or externally.
!
