Technical Information 40.2010 Page 17
TI_40_2010_13_01_02.fm
7.3 Aids
8. Spare parts
The spare parts lists will be available in time for the
market launch and are already contained on the
03/2010 edition of the STIHL Service
Communication System DVD.
9. Servicing
The specific national safety regulations and the
safety instructions in the instruction manual must be
observed if the machine has to be started up during
servicing.
9.1 Troubleshooting plan
The flow charts that follow deal with specific parts
diagnosis and troubleshooting for the M-Tronic
engine management system.
The flow charts help you to take the correct step at
the correct time.
Designation Part number Use
Set of gaskets 4147 007 1600 Engine
Set of carburetor parts 4147 007 1700 Carburetor
Grease (225 g tube) 0781 120 1111 Lubricating oil seals, sliding and bearing
points
Press fluid OH 723 0781 957 9000
STIHL gear lubricant for brushcutters Lubricating the gearbox and lubrication
between the rope rotor and starter post
– Tube 80 g 0781 120 1117
– Tube 225 g 0781 120 1118
STIHL multi-purpose grease Lubricating the drive shaft
– Tube 80 g 0781 120 1109
– Tube 225 g 0781 120 1110
Tube of sealant Dirko HT red 0783 830 2000 Sealing the crankcase
Standard solvent-based degreasant not
containing any chlorinated or
halogenated hydrocarbons
Cleaning mating surfaces and
carburetor, cleaning the crankshaft stub
and the cone in the flywheel
