-Removeshroud,see3.1.
•
Removescrew(1).
•
Removethrottlecableextension
(2).
•
Unhooknippleofthrottlecable
fromslottedpin(2)onthrottle
lever.
•
Pullthrottlecableoutoften-
sioner.
•
Disconnectplugofshort-circuit
wirefromsocketonignition
module.
•
Removeprotectivetubeon
throttlecablefromthrottlecable
holder.
-Removethrottletrigger,see7.1.
•
Slightlypullupcontactspring(1)
andremovethrottlecable(2).
Thepartsareassembledinrever-
seorder.
•
Ensurethatthrottlecable(1),
contactspring(2),protective
tube(3)andinsulatingelement
(4)arecorrectlyseated.
-Ensurethatshort-circuitwire
makescontactcorrectly.
392RA091
2 1
VA
392RA057
VA
392RA092
2
VA
1
392RA093
VA
7.2 Throttlecablewithoneshort-circuitwire
