Stihl HSE 61

26 HSE 61, HSE 71, HSE 81
5.4.2 Installing the gearbox
plate
From serial number 9 72 393 578
– Install the support plate, b 5.5.2
2
1
1
1
1
1
1
2
1
3
: Screw the motor and control unit
to the gear housing. Tighten
down the screws (1) to 1.5 Nm.
– Fit the switch lever (2) (loop
handle), b 7.5.2.
: Fit the front switch rod (3).
: Place the gear housing (1) with
its components in the motor
housing (2).
Important:
Check that wiring is properly
positioned (see next illustration).
