Stihl HSE 61

39HSE 61, HSE 71, HSE 81
: Turn the slide (1) in direction of
arrow and hold it in that position.
: Fit the spring (1) between the
slide (2) and handle molding (3).
1
3
1
2
: Push the slide (1) in direction of
arrow against the handle
molding.
Important:
The spring is preloaded. Take
care to ensure that the spring
does not pop out.
1
: Fit the handle molding with slide
(1) as shown in the illustration.
1
1
1
