Install Bar & Chain
 Make sure the cutters on top of the bar are facing away from
the powerhead!
WRONG
CORRECT
WRONG
© STIHL Inc., Virginia Beach, VA 2013 US/STR
confidential
Quick Chain Adjuster (QCA)
 The QCA allows the user to adjust the
chain tension without tools
Loosen the wing nut
Rotate the
adjusting wheel
Tighten the wing nut
