Stihl MS 194 C User Manual

MS 194 C
English
24
E = Hinge
N Helps control the falling tree.
N Do not cut through the hinge – you
could lose control of the direction of
the fall.
Felling Cut for Small Diameter Trees:
Simple Fan Cut
Engage the bumper spikes of the chain
saw directly behind the location of the
intended hinge and pivot the saw around
this point only as far as the hinge. The
bumper spike rolls against the trunk.
Felling Cut for Large Diameter Trees
WARNING
Felling a tree that has a diameter greater
than the length of the guide bar requires
use of either the sectioning felling cut or
plunge-cut method. These methods are
extremely dangerous because they
involve the use of the nose of the guide
bar and can result in kickback. Only
properly trained professionals should
attempt these techniques.
Sectioning Method
For the sectioning method make the first
part of the felling cut with the guide bar
fanning in toward the hinge. Then, using
the bumper spike as a pivot, reposition
the saw for the next cut.
001BA145 KN
E
E
001BA147 KN
001BA148 KN
1

Stihl MS 194 C Specifications

General

Engine Power	1.4 kW
Displacement	30.1 cm³
Weight	3.6 kg
Fuel Capacity	0.27 L
Chain Pitch	3/8" PM3
Guide Bar Length	30 cm (12")
