Stihl MS 261 C User Manual

13MS 261, MS 261 C
Condition Cause Remedy
Starter rope is difficult to pull or
rewinds very slowly
Starter mechanism is very dirty Thoroughly clean complete starter
mechanism
At very low outside temperatures:
Lubricating oil on rewind spring
becomes viscous (spring windings
stick togteher) or moisture has got
onto the rewind spring (spring
windings frozen together)
Coat rewind spring with a small
amount of standard solvent-based
degreasant (containing no
chlorinated or halogenated
hydrocarbons), then pull rope
carefully several times until normal
action is restored

Stihl MS 261 C Specifications

General

Displacement	50.2 cm³
Powerhead Weight	4.9 kg
Sound pressure level	103 dB(A)
Sound power level	116 dB(A)
Vibration level (left/right)	3.5/3.5 m/s²
Bar Length	40 cm (16 in.)
Fuel Capacity	500 cc
Oil Capacity	270 ml (9.1 oz.)
Chain pitch	3/8"
Engine Power	3.0 kW
