140 MS 261, MS 261 C
System in order
Expose and separate connectors of
handlebar heating element,
b
13.1.3
Test handlebar heating element
Resistance about 6.4Ω?
Check the heater switch
(connector sleeve against switch housing)
Closed: about 0Ω?
Open: Circuit interrupted,
b
13.4
Reconnect connector to
thermostatic switch,
b
13.1.3
no
no
Install new handlebar
b
9.6.1
Install new heater
switch,
b
13.4
yes
yes
1
2
3

Stihl MS 261 C Specifications

General

Displacement	50.2 cm³
Powerhead Weight	4.9 kg
Sound pressure level	103 dB(A)
Sound power level	116 dB(A)
Vibration level (left/right)	3.5/3.5 m/s²
Bar Length	40 cm (16 in.)
Fuel Capacity	500 cc
Oil Capacity	270 ml (9.1 oz.)
Chain pitch	3/8"
Engine Power	3.0 kW
