Stihl MS 261 C User Manual

65MS 261, MS 261 C
Check the flywheel:
– Have pole shoes turned blue?
– Install new flywheel if necessary,
b
7.6
Air gap:
– Check ignition module/flywheel,
– reset if necessary,
b
7.3
Check the ignition lead:
– Severe chafing?
– Spark plug boot: Holes/cracks?
– Resistance: spark plug boot to ground:
spec. 1.5 – 12 kΩ
– Check resistance of ignition lead (spark plug
boot and ignition module removed)
Spec.: < 10 Ω,
If necessary, install new spark plug boot and/or
ignition lead with module,
b
7.5
Check short circuit wire:
– Wire damaged?
– Connectors firmly seated?
– Check continuity, replace wiring harness if
necessary,
b
7.7.1
1
3
yes
no
2
Ignition spark?

Stihl MS 261 C Specifications

General

Displacement	50.2 cm³
Powerhead Weight	4.9 kg
Sound pressure level	103 dB(A)
Sound power level	116 dB(A)
Vibration level (left/right)	3.5/3.5 m/s²
Bar Length	40 cm (16 in.)
Fuel Capacity	500 cc
Oil Capacity	270 ml (9.1 oz.)
Chain pitch	3/8"
Engine Power	3.0 kW
