0458-620-8221-A
27
English
11 During Operation
WARNING
To reduce the risk of fluid injection and/or severe injury,
keep hands, feet or any other part of your body away from
the water jet at all times and never direct the high-pressure
jet toward yourself or other persons, not even to clean
clothing or shoes, @ 5.8.4. Do not direct the high-pressure
jet toward animals.
Depending on the application, the following nozzles may be
used:
Fan-jet nozzle: The fan-jet nozzle is designed for cleaning
larger areas.
Rotary-jet nozzle: The rotary nozzle is designed for
removing stubborn dirt.
If you want to remove stubborn dirt, reduce the distance
between the nozzle and the surface.
If you want to remove dirt from painted, wooden or other
potentially sensitive surfaces, increase the distance
between the nozzle and the surface.
To adjust the fan jet nozzle:
WARNING
To reduce the risk of injury from high-pressure spray, always
switch off the pressure washer, relieve any remaining
pressure in the system and lock the spray gun trigger before
attempting to insert, adjust or remove the spray nozzle.
Switch off the pressure washer.
Relieve system pressure.
Lock the spray gun trigger.
Rotate the fan-jet nozzle in the + direction to increase the
working pressure.
Rotate the fan-jet nozzle in the direction to reduce the
working pressure.
To clean:
Before starting work, direct the water jet at an
inconspicuous area of the surface and check that the
surface is not damaged.
Work at a distance that allows you to effectively clean the
surface without damaging it.
Adjust the fan-jet nozzle and distance from the surface to
be cleaned ensure the surface will not be damaged by the
spray.
Move the spray attachment evenly along the surface to be
cleaned.
Move forward slowly in a controlled manner.
0000-GXX-4628-A0
0000-GXX-5094-A0

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl RE 110 and is the answer not in the manual?

Stihl RE 110 Specifications

General IconGeneral
Form factorUpright
Hose length7 m
Cable length5 m
Power sourceElectric
Product colorBlack, Orange
Pump materialAluminum
Detergent tank-
Maximum flow rate440 l/h
Minimum flow rate380 l/h
Sound power level81 dB
Vibration emission1.8 m/s²
Working pressure (max)120 bar
Working pressure (min)110 bar
Maximum water temperature40 °C
AC input voltage230 V
Power consumption (typical)- W
Weight and Dimensions IconWeight and Dimensions
Weight17600 g
