0458-620-0121-A
28
English
15 Cleaning
15.2 Cleaning the nozzle and spray lance
► Flush nozzle and spray lance under running water and dry
with a cloth.
► If the nozzle is blocked up: Clean the nozzle with the
cleaning pin.
15.3 Cleaning the water intake screen
► Unscrew connector (1) of water connection.
► Pull water intake screen (2) out of water connection.
► Flush water intake screen (2) under running water.
► Insert water intake screen (2) into water connection.
► Screw on connector (1) and tighten it by hand.
15.4 Cleaning the water filter
The water filter must be disassembled to clean it.
► Remove gasket (1) from the fastener (2).
► Unscrew fastener (2) from filter housing (5).
► Remove gasket (3) from the fastener (2).
► Remove filter (4) from the filter housing (5).
► Rinse gaskets (1 and 3), fastener (2) and filter (4) under
running water.
0000-GXX-4369-A0
0000-GXX-4370-A0
1
2
0000-GXX-4372-A0
