19 Specifications
18.2 Greasing the gaskets
► Grease gaskets (1) with grease for fittings.
19.1 Pressure washer STIHL RE 110
Version 230V, 50Hz
– Fuse (characteristic "C" or "K"): 10 A
– Power consumption: 1.7 kW
– Electrical protection class: I
– Degree of electrical protection: IPX5 (protection from
water jets in any direction)
– Working pressure (p): 11 MPa (110 bar)
– Max. permissible pressure (p max.): 12 MPa (120 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Max. water throughput (Q min): 7.3 l/min (440 l/h)
– Max. suction lift: 1 m
– Max. water temperature in pressure mode (t in max):
40 °C
– Max. water temperature in suction mode: 20 °C
– Dimensions
– Length: 419 mm
– Width: 352 mm
– Height in operating position: 900 mm
– Height in transport position: 625 mm
– Length of high-pressure hose: 7 m
– Weight (m) with accessory attached: 17.6 kg
Version 120 V / 60 Hz
– Fuse (characteristic "C" or "K"): 15 A
– Power consumption: 1.4 kW
– Electrical protection class: I
– Degree of electrical protection: IPX5 (protection from
water jets in any direction)
– Working pressure (p): 8.4 MPa (84 bar)
– Max. permissible pressure (p max.): 10 MPa (100 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Max. water throughput (Q min): 7.3 l/min (440 l/h)
– Max. suction lift: 0.5 m
– Max. water temperature in pressure mode (t in max):
40 °C
– Max. water temperature in suction mode: 20 °C
– Dimensions
– Length: 419 mm
– Width: 352 mm
– Height in operating position: 900 mm
– Height in transport position: 625 mm
– Length of high-pressure hose: 7 m
– Weight (m) with accessory attached: 17.6 kg
Version 127 V / 60 Hz
– Fuse (characteristic "C" or "K"): 15 A
– Power consumption: 1.4 kW
– Electrical protection class: I
– Degree of electrical protection: IPX5 (protection from
water jets in any direction)
19 Specifications
