Stihl RE 130 PLUS User Manual

0458-624-8221-A
26
English 12 After Finishing Work
► If you want to remove stubborn dirt, reduce the distance
between the nozzle and the surface.
► If you want to remove dirt from painted, wooden or other
potentially sensitive surfaces, increase the distance
between the nozzle and the surface.
To adjust the fan jet nozzle:
WARNING
To reduce the risk of injury from high-pressure spray, always
switch off the pressure washer, relieve any remaining
pressure in the system and lock the spray gun trigger before
attempting to insert, adjust or remove the spray nozzle.
► Switch off the pressure washer.
► Relieve system pressure.
► Lock the spray gun trigger.
► Rotate the fan-jet nozzle in the + direction to increase the
working pressure.
► Rotate the fan-jet nozzle in the – direction to reduce the
working pressure.
To clean:
► Before starting work, direct the water jet at an
inconspicuous area of the surface and check that the
surface is not damaged.
► Work at a distance that allows you to effectively clean the
surface without damaging it.
► Adjust the fan-jet nozzle and distance from the surface to
be cleaned ensure the surface will not be damaged by the
spray.
► Move the spray attachment evenly along the surface to be
cleaned.
► Move forward slowly in a controlled manner.
12.1 Preparing for Transportation or Storage
To prepare the pressure washer for transportation or
storage:
► Switch off the pressure washer, @ 10.2.
► Disconnect the pressure washer from the power supply.
► Disconnect the pressure washer from the water supply.
► Press the spray gun trigger to relieve any remaining
pressure in the system.
► Lock the spray gun trigger.
► Disconnect the water hose.
► Remove and clean the nozzle and spray lance.
► Remove the spray gun and let the rest of the water run out
of the spray gun.
► If the pressure washer will be exposed to freezing
temperatures, protect it with antifreeze or take other
measures outlined below, @ 12.2.
0000-GXX-4628-A0
12 After Finishing Work
0000-GXX-5094-A0

Stihl RE 130 PLUS Specifications

General

Form factor	Upright
Hose length	9 m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	500 l/h
Minimum flow rate	400 l/h
Sound power level	86 dB
Vibration emission	2.4 m/s²
Working pressure (max)	150 bar
Working pressure (min)	135 bar
Maximum water temperature	40 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	21200 g
