RE 143, RE 143 PLUS, RE 163, RE 163 PLUS
English
48
Disconnecting the high-pressure hose
N Pull out the spring clip (1) and pull
the high-pressure hose (2) out of
the connector
Connecting the high-pressure hose
N Push the high-pressure hose (2)
onto the connector of the hose reel
N Push the spring clip (1) into the
connector
High-pressure hose and spray gun
Fitting
N Push the connector of the high-
pressure hose (3) into the mount on
the spray gun (4) – until it engages
Removing
N Actuate the safety catch (5) and pull
the high-pressure hose (3) out of
the mount on the spray gun
High-pressure hose extension
As a rule, always use only one high-
pressure hose extension – see "Special
accessories"
In suction operation, the machine can
also be connected to rivers, lakes,
cisterns and tanks, etc. – see
"Connecting to a pressureless water
supply".
Briefly rinse out the hose before
connecting it to the machine to prevent
sand and other particles from entering
the machine.
Connecting the hose
N Connect hose to water supply (1/2"
diameter, length at least 10 m to
absorb pressure surges. Maximum
length 25 m)
N Push the coupling (1) on to the hose
connector (2)
N Turn on water supply
1607BA051 KN
1
2
650BA013 KN
4
5
3
Connecting the water supply
2
1607BA052 KN
1
