0478-131-9541-A
15
English
8 Removing and Fitting the Battery
7.3 Assembling, Attaching and Detaching the Grass
Catcher Box
7.3.1 Assembling the Grass Catcher Box
► Fit upper part of grass catcher box (1) onto lower part of
grass catcher box (2).
► Press pins (3) through openings (4) from the inside.
► Press upper part of grass catcher box (1) downwards.
The upper part of the grass catcher box engages with a
click.
7.3.2 Attaching the Grass Catcher Box
► Switch the lawn mower off.
► Place the lawn mower on a level surface.
► Open discharge flap (1) and hold it open.
► Take hold of grass catcher box (2) by handle (3) and
attach to mounts (4) using the hooks.
► Set down discharge flap (1) on grass catcher box (2).
7.3.3 Detaching the Grass Catcher Box
► Switch the lawn mower off.
► Place the lawn mower on a level surface.
► Open the discharge flap and hold it open.
► Remove the grass catcher box upwards by the handle.
► Close the discharge flap.
8.1 Fitting the Battery
► Place the lawn mower on a level surface.
► Open flap (1) as far as the stop and hold.
► Push battery (2) into battery compartment (3) as far as it
will go.
Battery (2) engages with a click and is locked in place.
► Close flap (1).
8.2 Removing the Battery
► Place the lawn mower on a level surface.
► Open flap (1) as far as the stop and hold.
8 Removing and Fitting the Battery
