Stihl RMA 235 User Manual

0478-131-9541-A
27
English 20 Specifications
20.1 STIHL RMA 235.0 Lawn Mower
– Permissible battery: STIHL AK
– Weight without battery: 14 kg
– Maximum grass catcher box capacity: 30 l
– Cutting width: 33 cm
– Speed: 3,400 rpm
– Speed in ECO mode: 2,900 rpm
For information on the battery life see
www.stihl.com/battery-life.
20.2 Blade
– Minimum thickness a: 1.6 mm
– Minimum width b: 56 mm
– Sharpening angle c: 30°
20.3 STIHL AK Battery
– Battery technology: Lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
– Permissible temperature range for operation and storage:
-10°C to +50°C
20.4 Sound Values and Vibration Values
The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 1.5 dB(A). The K value for
the vibration values is 0.9 m/s².
– Sound pressure level L
pA
measured in accordance with
EN 60335-2-77: 76 dB(A)
– Sound power level L
wA
measured in accordance with
2000/14/EC: 87.9 dB(A)
– Vibration value a
hv
measured in accordance with EN
60335-2-77, handlebar: 1.8 m/s²
The indicated vibration values have been measured in
accordance with a standardised test method and can be
used for the purpose of comparing electrical appliances. The
actual vibration values that occur may deviate from the
indicated values, depending on the type of application. The
indicated vibration values can be used for an initial
assessment of the vibration load. The actual vibration load
must be assessed. Times during which the electrical
appliance is switched off, along with times in which it is
switched on but running without load, can also be taken into
consideration.
For information on compliance with Employers' Vibration
Directive 2002/44/EC see www.stihl.com/vib.
20.5 Normative Information
STIHL Tirol GmbH
Hans Peter Stihl-Strasse 5
6336 Langkampfen
Austria
confirms that the machine complies with the regulations in
implementation of the following standards IEC 60335-1 and
IEC 60335-2-77.
20 Specifications

Stihl RMA 235 Specifications

General

Type	Walk behind lawn mower
Cutting width	330 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.9 m/s²
Housing material	Plastic
Number of wheels	4 wheel(s)
Rotational speed	3400 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	89 dB
Handle(s) features	Foldable
Standard deviation	2 dB
Vibration emission	1.8 m/s²
Sound pressure level	87.9 dB
Maximum cutting height	60 mm
Minimum cutting height	25 mm
Grass collecting volume	30 L
Number of height positions	5
Power source	Battery
Power consumption (typical)	450 W

Weight and Dimensions

Weight	14000 g
