Stihl RMA 339 C User Manual

0478 131 8327 B - EN
16
7.1 General points
● Place the machine on level, firm ground
when performing all the operations
described.
● Charging the battery (Ö 8.4).
7.2 Installing the mono handlebar
(RMA 339 C)
● 1 Insert sleeve (E) in the bore on
handlebar (1).
● 2 Fit two washers (G) with the convex
side facing inwards onto the sleeve.
● 3 Hold sleeve (E) and washers (G)
and insert together with handlebar (1)
into bracket (2).
● 4 Insert nut (H) into the bracket as
shown.
● 5 Insert bolt (F) from the outside
inwards through the bores in
handlebar (1) and in bracket (2).
● 6 Tighten bolt (F).
Tightening torque:
18 - 22 Nm
Installing the electric cable:
● Insert the electric cable as shown into
cable guide (3),
● press into the holder on handlebar (4)
and
● fasten to the handlebar using cable
clip (5).
7. Preparing the machine for
operation
Risk of injury.
Observe the safety instructions in
the section "For your safety" (Ö 4.).
Remove the safety plug,
particularly before
performing any work on the lawn
mower (Ö 9.2).
The batteries are charged to
approx. 30% on delivery. They must
be therefore be charged before
being used for the first time.

Stihl RMA 339 C Specifications

General

Type	Walk behind lawn mower
Cutting width	370 mm
Grass catcher	Yes
Product color	Black, Green, Orange
Uncertainty K	0.8 m/s²
Cutting system	Rotary blades
Number of wheels	4 wheel(s)
Rotational speed	3350 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.6 m/s²
Rear wheels diameter	180 mm
Sound pressure level	89.4 dB
Front wheels diameter	150 mm
Maximum cutting height	70 mm
Minimum cutting height	30 mm
Grass collecting volume	40 L
Suitable for slope up to	25 °
Power source	Battery
Battery voltage	36 V
Power consumption (typical)	900 W

Weight and Dimensions

Width	420 mm
Height	1070 mm
Weight	16000 g
