Stihl RMA 339 C User Manual

EN
3
0478 131 8327 B - EN
Dear Customer,
Thank you for choosing STIHL. We
develop and manufacture our quality
products to meet our customers'
requirements. The products are designed
for reliability even under extreme
conditions.
STIHL also stands for premium service
quality. Our specialist dealers guarantee
competent advice and instruction as well
as comprehensive service support.
We thank you for your confidence in us
and hope you will enjoy working with your
STIHL product.
Dr. Nikolas Stihl
IMPORTANT: READ BEFORE USE AND
KEEP IN A SAFE PLACE.
Printed on chlorine-free bleached paper. Paper is recyclable. Cover is halogen free.
1. Table of contents
Notes on the instruction manual 4
General 4
Instructions for reading the
instruction manual 4
Country-specific versions 5
Machine overview 6
For your safety 7
General 7
Clothing and equipment 8
Battery 8
Charger 9
Charging 9
Transporting the machine 10
Transporting the battery 10
Before operation 10
Working with your machine 11
Maintenance, cleaning, repairs and
storage 12
Storage for prolonged periods
without operation 13
Disposal 13
Description of symbols 13
Standard equipment 15
Preparing the machine for
operation 16
General points 16
Installing the mono handlebar
(RMA 339 C) 16
Installing the dual handlebar
(RMA 339) 17
Assembling the grass catcher box 17
Battery and charger 18
General 18
Connecting the charger to the
mains 18
Removing/inserting the battery 18
Charging the battery 19
LEDs on the battery 19
LED on the charger 20
Controls 20
Battery compartment 20
Safety plug 20
Eco mode switch 21
Adjusting the mono handlebar
(RMA 339 C) 21
Folding down the dual handlebar
(RMA 339) 21
Central cutting height adjustment 22
Grass catcher box 22
Level indicator 23
Notes on working with the
machine 23
General 23
Cutting performance 23
Working area for operator 23
Correct motor load 24
If the mowing blade blocks 24
Thermal motor overload protection 24
Safety devices 24
Safety plug 24
Safety devices 24
Two-hand operation 24
Motor run-down brake 24
Operating the machine 24
Preparatory measures 24
Switching the lawn mower on 24
Switching the lawn mower off 25
Emptying the grass catcher box 25
Maintenance 26
General 26
Cleaning the machine 26
Electric motor and wheels 27

Stihl RMA 339 C Specifications

General

Type	Walk behind lawn mower
Cutting width	370 mm
Grass catcher	Yes
Product color	Black, Green, Orange
Uncertainty K	0.8 m/s²
Cutting system	Rotary blades
Number of wheels	4 wheel(s)
Rotational speed	3350 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.6 m/s²
Rear wheels diameter	180 mm
Sound pressure level	89.4 dB
Front wheels diameter	150 mm
Maximum cutting height	70 mm
Minimum cutting height	30 mm
Grass collecting volume	40 L
Suitable for slope up to	25 °
Power source	Battery
Battery voltage	36 V
Power consumption (typical)	900 W

Weight and Dimensions

Width	420 mm
Height	1070 mm
Weight	16000 g
