EN
21
0478 131 8327 B - EN
● Lift up battery compartment cover (1) at
the front and hold in the open position.
(Ö 9.1)
● Removing:
Remove safety plug (2) from socket (3)
and keep separately from the lawn
mower.
Inserting:
Press safety plug (2) into socket (3) as
far as it will go.
● Close battery compartment cover (1).
9.3 Eco mode switch
The eco mode switch that increases
battery running time is located in the
battery compartment. (Ö 10.2)
Switching on eco mode:
● Move switch to position I.
Switching off eco mode:
● Move switch to position 0.
9.4 Adjusting the mono handlebar
(RMA 339 C)
Folding down the handlebar:
Transport position (for cleaning, for
space-saving transport and for storage of
the machine):
● Hold upper handlebar (2) at its highest
point with one hand and lift (relieve
load) slightly.
● Press detent lever (1) downwards and
hold.
● Fold handlebar (2) down forwards,
ensuring that the electric cable is not
damaged.
Working position (to push machine):
● Fold handlebar (2) up rearwards and
ensure that the handlebar is fully
engaged.
Height adjustment:
The height of the mono handlebar can be
adjusted to 2 levels:
● Hold upper handlebar (2) at its highest
point with one hand and lift (relieve
load) slightly.
● Press detent lever (1) downwards and
hold.
● Move handlebar (2) into the required
position.
● Release detent lever (1) and ensure
that the handlebar is again fully
engaged.
9.5 Folding down the dual handlebar
(RMA 339)
Danger of pinching!
When operating the detent lever,
always hold the upper handlebar at
its highest point with one hand.
Never place your fingers between
the handlebar and bracket (above
and below the detent lever).
Danger of pinching!
The upper handlebar can fold down
when the rotary handles are
released. Therefore hold the upper
handlebar with one hand at its
highest point when unscrewing the
rotary handles.
