Stihl RMA 339 C User Manual

0478 131 8327 B - EN
34
– Charger power supply faulty
Remedy:
– Remove battery from battery
compartment and reinsert (Ö 8.3)
– Connect charger to the mains (Ö 8.2)
– Check mains power supply
– Check charger, replace if necessary
(#)
Fault:
LED on charger flashes red
Possible cause:
– No electrical contact between charger
and battery
– Battery defective (4 LEDs on the
battery flash red for approx. 5 seconds)
– Charger defective
Remedy:
– Remove battery from battery
compartment and reinsert (Ö 8.3)
– Check battery, replace if necessary (#)
– Check charger, replace if necessary
(#)
20.1 Handover confirmation
20.2 Service confirmation
Please hand this instruction manual
to your STIHL specialist dealer in
the case of maintenance operations.
He will confirm the service operations
performed in the pre-printed boxes.
20. Service schedule
Service performed on
Next service date
1

Stihl RMA 339 C Specifications

General

Type	Walk behind lawn mower
Cutting width	370 mm
Grass catcher	Yes
Product color	Black, Green, Orange
Uncertainty K	0.8 m/s²
Cutting system	Rotary blades
Number of wheels	4 wheel(s)
Rotational speed	3350 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.6 m/s²
Rear wheels diameter	180 mm
Sound pressure level	89.4 dB
Front wheels diameter	150 mm
Maximum cutting height	70 mm
Minimum cutting height	30 mm
Grass collecting volume	40 L
Suitable for slope up to	25 °
Power source	Battery
Battery voltage	36 V
Power consumption (typical)	900 W

Weight and Dimensions

Width	420 mm
Height	1070 mm
Weight	16000 g
