Stihl RMA 339 C User Manual

0478 131 8327 B - EN
18
8.1 General
The RMA 339, RMA 339 C lawn mowers
are operated with rechargeable STIHL AK
type lithium-ion batteries only.
The batteries supplied are optimally
adapted to the intended purpose,
however, all STIHL AK type batteries can
be used.
The lawn mower electronics exchange
data with the installed battery and adapt
the power of the electric motor to the
relevant capacity.
8.2 Connecting the charger to the
mains
● Insert mains plug (1) in socket (2).
● After connection of the charger to the
power supply, a self-test is performed.
During this process, LED (3) on the
charger illuminates green for approx.
1 second, then red and then
extinguishes again (Ö 8.6).
8.3 Removing/inserting the battery
● Remove the safety plug
(Ö 9.2) and hold the battery
compartment cover in the
open position.
Removing the battery:
● Push locking lever (1) towards the
battery and remove battery (2)
upwards.
8. Battery and charger

Stihl RMA 339 C Specifications

General

Type	Walk behind lawn mower
Cutting width	370 mm
Grass catcher	Yes
Product color	Black, Green, Orange
Uncertainty K	0.8 m/s²
Cutting system	Rotary blades
Number of wheels	4 wheel(s)
Rotational speed	3350 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.6 m/s²
Rear wheels diameter	180 mm
Sound pressure level	89.4 dB
Front wheels diameter	150 mm
Maximum cutting height	70 mm
Minimum cutting height	30 mm
Grass collecting volume	40 L
Suitable for slope up to	25 °
Power source	Battery
Battery voltage	36 V
Power consumption (typical)	900 W

Weight and Dimensions

Width	420 mm
Height	1070 mm
Weight	16000 g
