EN
29
0478 131 8327 B - EN
Only store the lawn mower in good
operating condition, fold down the
handlebar if necessary.
Keep all nuts, pins and bolts tightly
fastened, replace danger signs and
warnings on the machine that have
become illegible, check the entire machine
for wear and damage. Replace all worn or
damaged parts.
Any machine faults must be completely
remedied prior to storage.
Note the following points when storing the
lawn mower for long periods (winter
break):
Clean all external parts of the machine
with care.
Thoroughly lubricate/grease all moving
parts.
Storing the battery:
Remove battery from the battery
compartment or out of the charger.
Clean the battery.
Store the battery in a dry locked place
that is generally free of dust in
electrically non-conductive packaging.
Ensure that batteries are protected from
unauthorised use (e.g. by children).
Do not store spare batteries unused –
use batteries alternately.
For optimum battery service life,
observe the permissible temperature
range (Ö 18.1) and store the battery at
a charge state between 20% and 40%
(2 LEDs illuminated green).
Storing the charger:
Remove the battery and remove the
mains plug from the socket.
Clean the charger.
Store the charger separately from the
battery in a dry, locked and dust-free
room. Ensure that it is protected from
unauthorised use (e.g. by children).
Do not suspend the charger from the
electric cable.
14.1 Carrying and securing the lawn
mower
Carrying the machine:
Only lift the lawn mower by transport
handles (1, 2). Always ensure sufficient
distance between the mowing blade
and your body, particularly your feet
and legs.
14. Transport
Risk of injury!
Observe the safety instructions in
the section "For your safety" (Ö 4.).
Remove the safety plug,
particularly before
performing any work on the lawn
mower (Ö 9.2).
Exercise special care when
transporting lithium ion batteries
(Ö 4.3).

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl RMA 339 C and is the answer not in the manual?

Stihl RMA 339 C Specifications

General IconGeneral
TypeWalk behind lawn mower
Cutting width370 mm
Grass catcherYes
Product colorBlack, Green, Orange
Uncertainty K0.8 m/s²
Cutting systemRotary blades
Number of wheels4 wheel(s)
Rotational speed3350 RPM
Maximum lawn area- m²
Mulching function-
Sound power level90 dB
Handle(s) featuresFoldable
Vibration emission1.6 m/s²
Rear wheels diameter180 mm
Sound pressure level89.4 dB
Front wheels diameter150 mm
Maximum cutting height70 mm
Minimum cutting height30 mm
Grass collecting volume40 L
Suitable for slope up to25 °
Power sourceBattery
Battery voltage36 V
Power consumption (typical)900 W
Weight and Dimensions IconWeight and Dimensions
Width420 mm
Height1070 mm
Weight16000 g
