Using additional fork controls (only for model LTX FF)
2419
2
1
3 4
5
Fork upward tilt button
Fork downward tilt button
Fork opening button
Fork closing button
1
2
3
4
"LiftRunner" trailer lifting/lowering control.
The control is optional and described in sec-
tion
5
NOTE
The following controls are active with the truck
switched on and the operator standing on the
platform in the correct "working position", and
only if the control has not already reached the
end position.
DANGER
Stepping onto the forks is forbidden!
Do not use the controls while standing on the forks.
Use
4
Moving the load
