Capacity label for tow tractors
(LTX50, LTX-FF, LTX-T) with
rear coupling
The label is only present on tow tractors fitted
with a rear tow coupling.
NOTE
The values indicated refer to the towing limits
with the truck in
forward travel
and must not
be exceeded, otherwise the stability of the
truck and the load-bearing capacity of the
structures may be compromised.
The trailer coupled to the truck must not ex-
ceed the maximum permissible weight of
5000 kg. The maximum permissible pulling
force on the coupling during towing is 1000 N.
Qmax=5000 kg
F=1000 N
2556
Overview
3
Markings
70 45878043344 EN - 11/2021 - 12
