Sistemi di illuminazione
2366
2
1
2
9
3
6
10
7
9
8
A
B
C
D
E
4
5
F
LED light bar
Blue safety spotlights
Flashing beacon
Arrows (direction indicators)
Multifunction lights
Working spotlight
Dipped-beam lights
1
2
3
4–5
6–7
8
9
Reverse lights
Dipped-beam lights and light bar push but-
ton
Flashing beacon push button
Arrow push buttons (direction indicators)
Hazard lights push button
Working spotlight switch
10
A
B
C–D
E
F
Overview
3
Options and variants
88 45878043344 EN - 11/2021 - 12
