Still LTX 50 - General Overview LTX-T

General overview LTX-T
2403
1
24
3
4
5
16
15
18
18
8
10
17
19
12
13
14
16
6
11
20
21
5
7
22
23
9
2
25
Steering wheel with integrated controls
Drive wheel
Hood for accessing the battery compartment
Motor compartment hood
Battery
Platform damping system
Rear wheels
Tow coupling
Trailer lighting socket
Dashboard
12/24 V cigarette lighter socket
Emergency stop button
1
2
3
4
5
6
7
8
9
10
11
12
On/off key
Digicode - Numerical keypad
Ballast
Operator platform
Document holder
Storage compartment
Battery plug and socket
Power current plug of the on-board battery
charger
Mechanical battery lock clasp
Seat backrest
Rear cover
13
14
15
16
17
18
19
20
21
22
23
