Capacity plate LTX-FF
DANGER
The values indicated on the capacity plate refer to
compact and uniform loads and must not be excee-
ded — otherwise the stability of the truck, the trailer
and the load-bearing capacity of the structures may
be compromised.
Capacity plate for lifting a load on the forks.
The plate contains the following information:
●
(A) Shows the maximum capacity of the
truck (kg) with the load centre of gravity up
to 500 mm and with the forks at the maxi-
mum height of 1800 mm (C).
●
(B) Shows the maximum capacity of the
truck (kg) with the load centre of gravity at
600 mm and with the forks at the maximum
height (C).
2420
C
B
A
Overview
3
Markings
6745878043344 EN - 11/2021 - 12
