Installation (Cont.)
Positioning the Appliance
• Ensure that the aperture that you will be fitting the oven into is of the size
given in Fig. 2, opposite.
• The oven must be fitted into an oven housing with the ventilation cut-outs
shown in Fig. 4 below.
• Ensure that the rear panel of the furniture housing unit has been removed.
Fig. 4: Ventilation and cut-out requirements for the installation of the
appliance into a standard kitchen unit
Fig. 4
